DESCRIPTION
The A52SNV1 component is a conductor-loaded, multilayered Substrate Integrated Waveguide (SIW) bandpass filter, having an extremely low profile and a high Q factor of over 200. The filter is surface mountable and able to handle RF powers up to 1 W. Its passband insertion loss between 50.4 GHz to 54.2 GHz is less than 2.5 dB, with return losses of no less than 20 dB. The input/output pads are impedance matched to 50 Ω, however, this can be altered to suit customer requirements.
MAIN FEATURES
- Very low profile, less than 0.5 mm
- High Q factor
- Surface mount package
- Shielded component
- 50 Ω characteristic impedance.
ELECTRICAL SPECIFICATIONS
MAXIMUM SETTINGS
TYPICAL RESPONSE
DIMENSIONS
SUGGESTED PAD LAYOUT
Notes:
- Shown Coplanar waveguide must match input impedance of the filter, 50 Ω in this case.
- Vias need to be a maximum 150 µm in diameter and via edge-to-edge separation of 150 µm.
- The bottom side of filter is continuous ground plane. Ensure good electrical contact with carrier substrate.
- Numbering: 1: input; 2: output.
